Network Cameras
CPRO-FN-5136ND

Key Feature

  • ** 36ch HD-NVR **
    HD-NVR With None PoE

    * Features :
    36Ch Real Time Display and Real time Recording
    Throughput 200Mbps for 36Ch(Min. 2ea of HDD should be installed)
    ONVIF Compatible & Auto IP Camera Detection/Registration
    Dual(Main & Sub) Stream Recording/Display
    System Performance Monitoring (Bandwidth & Network Status, etc.)
    P2P Function that doesn’t require Port Forwarding
    iSCSI function Support – External HDD through Network
    Smart Search – Multiple search by time & minutes’ base
    Zero Configuration Supports
    H.264 & H.265 Supports


    * Specifications :
    Max HDD Bay/Min Installation : 4x SATA HDD / 2x SATA
    Video out : HDMI(Max UHD) & VGA
    Recording Speed : 1080fps
    Alarm Input/Relay Output : 16ch / 4ch
    LAN : 2EA Gigabit Ethernet(RJ45)-Foxed IP, DHCP & DDNS, DHCP server embedded
    Throughput (Bandwidth(Max)) : 200Mbps
    System operating Power : SMPS (110~240V AC) Max 145W
    Dimension(WxDxH) : 445 x 400 x 71 mm(~1.6U)

Specifications

PDF
Mechanical
Housing Model none
